17-8 IM 701450-01E
17.9 USB Peripheral Interface
Item Specifications
Connector type USB type A connector (receptacle)
Electrical and mechanical Conforms to USB Revision 1.1
specifications
Data rate 12 Mbps max.
Supported keyboards 104 keyboard (US), 109 keyboard (Japanese), and 89 keyboard (US and Japanese)
conforming to USB HID Class Version 1.1
Supported printers ESC/P, ESC/P2, LIPS3, PCL5, and BJ (can be used on models that support the BJC-35V
native commands) that support USB (USB Printer Class Version 1.0)
Supported mouse Mouse conforming to USB HID Class Version 1.1
Supports USB mass storage USB mass storage class hard disk drive, MO disk drive, and flash memory
Power supply 5 V, 500 mA* (per port)
Number of ports 2
* Devices with maximum consumption currents exceeding 100 mA cannot be connected to two ports at the same time.
17.10 Auxiliary I/O Section
External Trigger Input
1
and Trigger Gate Input
1
Item Specifications
Connector type BNC
Input bandwidth
2
DC to 100 MHz
3
Input impedance Approx. 1 MΩ and 22 pF
Maximum input voltage ±40 V (DC+ACpeak) or 28 Vrms when the frequency is 10 kHz or less.
Trigger level ±2 V (resolution of 5 mV)
1 The external trigger input terminal (EXT TRIG IN)/trigger gate input terminal (TRIG GATE IN) is also used as an external
clock input terminal (EXT CLOCK IN). See the specifications of the external clock input (see section 17.4).
2 Under standard operating conditions (see section 17.12) after the warm-up.
3 The input frequency range when using the terminal as a trigger gate input is DC to 50 MHz.
Trigger Output (TRIG OUT)
Item Specifications
Connector type BNC
Output level TTL
Output logic (Negative)
Output delay time 50 ns max
Output hold time 1 µs minimum for low level and 100 ns minimum for high level
Video Signal Output (VIDEO OUT (VGA))
Item Specifications
Connector type 15-pin D-Sub receptacle
Output type VGA compatible
Probe Power Supply Terminal
Item Specifications
Number of output terminals 4 (A to D)
(4 optional terminals (E to H) can be added on the 8-channel model).
Output voltage +12 V (Up to ±500 mA on each pair of terminals A and E; B and F; C and G; and D and H.)
Probes that can be used FET probe (700939), current probe (700937, 701930, 701931, 701932, or 701933), and
differential probe (701920 or 701922)
To Next Page
