YOKOGAWA DL7440 User Manual

6-6 IM 701450-01E
6.4 Setting the Hold Off Time
Procedure
For Simple Triggers
SEARCH
PRESET ZOOM MODE
POSITION
ENHANCED
SIMPLE
LOGIC
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
CH 7
CH 8
V/DIV TIME/DIV
VERTICAL TRIGGER
TRIG D
ACTION
DELAY
CLEAR TRACESNAPSHOT HELP
HORIZONTAL
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
1. Press SIMPLE. The SIMPLE (Edge) menu appears.
2. Press the Hold Off soft key.
3. Turn the jog shuttle to set the hold off time.
Pressing RESET resets the value to 0.08 us.
