YOKOGAWA DL7440 User Manual

4-23
IM 701450-01E
4
Common Operations
4.8 Using the Help Function
Procedure
SEARCH
PRESET ZOOM MODE
POSITION
ENHANCED
SIMPLE
LOGIC
CH 1
CH 2
CH 3
CH 4
CH 5
CH 6
CH 7
CH 8
V/DIV TIME/DIV
VERTICAL TRIGGER
TRIG D
ACTION
DELAY
CLEAR TRACESNAPSHOT HELP
HORIZONTAL
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
Displaying the Help Window
1. Press HELP. The help window appears.
2. Press the panel key or soft key that you wish to review.
Clearing the Help Window
3. Press HELP again. The help window disappears.
Explanation
Displaying the Help Window
When you press HELP, a help window containing information about the soft key menu or
jog shuttle menu that was displayed immediately before HELP was pressed appears.
If you press a key while the help window is displayed, a help window containing
information about the key appears.
Clearing the Help Window
If you press HELP again while a help window is displayed, the help window closes.
