13.7 Using the Web Server Function
You can use the Web server function on the DL7400 to display the screen image of the
DL7400 on your PC’s Web browser and perform file operations on the DL7400 using the
keys displayed in the Web browser.
This section contains the following information.
• Overview of the Web server function -> See this page.
• System Requirements
• PC environment -> See page 13-19.
• DL7400 environment -> See page 13-20.
• Preparations for using the Web server function
• Preparations on the DL7400 -> See page 13-21.
• Preparations on the PC -> See page 13-22.
• Using the Web server function
• Using the FTP server function -> See 13-26.
• Performing data capture -> See page 13-27.
• Displaying the measurement trend of waveform parameters
-> See page 13-32.
• Using control scripts -> See page 13-35.
• Showing the log -> See page 13-37.
• Showing the instrument information -> See page 13-39.
• Viewing the link destination -> See page 13-40.
Overview of the Web Server Function
FTP Server Function (on a Web Browser)
View the list of files stored on the storage medium of the DL7400 (built-in storage
medium) and transfer files to the PC.
Data Capture
The following operations can be performed.
• Change the display format of the DL7400 and display data that is acquired in the
history memory.
• Display the screen image of the DL7400.
• Save the waveform data and setup data to the PC.
• Load the setup data stored on the PC into the DL7400.
Displaying the Measurement Trend of Waveform Parameters
Using the Excel function, display the trend of the selected waveform parameter values.
The statistics of the measured values can also be computed.
Control Script
Control the DL7400 using communication commands (see the Communication Interface
User’s Manual (IM701450-17E)).
Log
Displays the past log of errors that occurred on the DL7400, GO/NO-GO determination,
and action-on-trigger. Up to the 30 newest incidents are logged.
Instrument Information
Displays the model of the DL7400, the presence/absence of options, the ROM version
(firmware version), etc.
Link
View the Web page for the DL7400.
