13-41
IM 701450-01E
13
Ethernet Communications (Optional)
13.8 Setting the Time Difference from GMT
(Greenwich Mean Time)
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• In the procedural explanation below, the term
jog shuttle & SELECT refers to the operation of
selecting/setting items and entering values using the
jog shuttle and SELECT and RESET keys. For details
on this operation, see sections 4.1 or 4.2.
• For a description of the operation using a USB keyboard
or a USB mouse, see section 4.3.
Setting the Time Difference from GMT (Greenwich Mean Time)
1. Press MISC. The MISC menu appears.
2. Press the Network soft key. The Network menu appears.
3. Press the Others soft key. The Others dialog box opens.
Hour
Minute
4. Use jog shuttle & SELECT to set the Time Hour of Time Difference From GMT
in the range of –12 to 13.
5. Likewise, set the Minute of Time Difference From GMT in the range of 0 to 59.
Note
Minute can be specified only if Time Hour is set in the range of –11 to 12. (Minute cannot be
specified if Time Hour is set to –12 or 13.)
Setting SNTP (Simple Network Time Protocol) (Firmware Version 1.30 or later)
6. Use the jog shuttle to set Exec at Power On to ON or OFF.
7. Use jog shuttle & SELECT to enter Server (IP address of the SNTP server).
8. Use jog shuttle & SELECT to enter Time out in the range of 1 to 60 (s).
To Next Page
