YOKOGAWA DL7440 User Manual

iv IM 701450-01E
NO. (Instrument Number)
When contacting the dealer from which you purchased the instrument, please give them
the instrument number.
Standard Accessories
The standard accessories below are supplied with the instrument.
Printer roll
paper
2
B9850NX
400 MHz passive
probe
700988
1
Rubber feet
(4 pieces)
(2 A9088ZM sheets)
Front panel
protection cover
B8051DP
Soft case
B
9969ET
Communication
Interface User’s
Manual B8051YZ
UL/CSA Standard
A1006WD
VDE Standard
A1009WD
BS Standard
A1054WD
AS Standard
A1024WD
D F Q R
Power Cord (one of the following power cords
is supplied according to the instrument’s suffix codes)
GB Standard
A1064WD
H
1 On models with the /EX4 option, 701941 passive probes are provided in place of 700988 passive probes.
2 Provided on models with the /B5 option (built-in printer).
3 Provided on models with the /G4 option (power supply analysis function).
4 Provided on models with the /F5, /F7, or /F8 option (bus analysis function).
5 Provided on models with the /F9 option (FlexRay Signal Analyzer).
User’s manual (this manual),
Operation Guide, Power Supply
Analysis Function User’s Manual
3
,
Serial Bus Signal Analysis Function
User’s Manual
4
, and FlexRay Signal
Analyzer User’s Manual
5
(1 piece each)
500 MHz miniature
passive probe
701941
1
Checking the Contents of the Package
