YOKOGAWA DL7440 User Manual

17-9
IM 701450-01E
17
Specifications
17.11 Computer Interface
GP-IB
Item Specifications
Electrical and mechanical Conforms to IEEE St’d 488-1978 (JIS C 1901-1987).
specifications
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, and C0
Protocol Conforms to IEEE St’d 488.2-1987.
Code ISO (ASCII) code
Mode Addressable mode
Address Specify a talker/listener address between 0 and 30.
Clear remote mode Remote mode can be cleared using the SHIFT+CLEAR key (except during Local Lockout).
USB
Item Specifications
Connector type USB type B connector (receptacle)
Electrical and mechanical Conforms to USB Revision 1.1.
specifications
Data rate 12 Mbps max.
Number of ports 1
PC system supported PC running Windows 98 SE, Windows Me, Windows 2000, or Windows XP with a standard
USB port (a separate driver is needed to connect to a PC).
Ethernet (Optional)
Item Specifications
Number of communication ports 1
Electrical and mechanical Conforms to IEEE802.3.
specifications
Transmission system Ethernet (100BASE-TX/10BASE-T)
Transmission rate 100 Mbps max.
Communication protocol TCP/IP
Supported services FTP server, FTP client (network drive), LPR client (network printer), SMTP client (mail
transmission), Web server, DHCP, DNS, SNTP*, and WebDAV*
Connector type RJ-45 connector
* SNTP and WebDAV are available only on models with a firmware version of 1.30 or later.
