11-11
IM 701450-01E
11
Printing Screen Images
11.4 Printing Using a Network Printer (Optional)
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• In the procedural explanation below, the term
jog shuttle & SELECT refers to the operation of
selecting/setting items and entering values using the
jog shuttle and SELECT and RESET keys. For details
on this operation, see sections 4.1 or 4.2.
• For a description of the operation using a USB keyboard
or a USB mouse, see section 4.3.
Configuring the Network
1. After making a network connection (see section 13.1), enter TCP/IP settings
(see section 13.2) and settings for printing screen images to a network printer
(see section 13.4.).
Selecting a Network Printer
2. Press SHIFT+PRINT (MENU). The PRINT menu appears.
3. Press the Print to soft key. The Print to menu appears.
Built-in and Net Print appear if the built-in printer option and the Ethernet interface
option are installed, respectively.
4. Press the Net Print soft key.
Selecting the Page Description Language or the Printer Type
5. Press the Format soft key. The Format menu appears.
6. Press Post Script, LIPS3, PCL5, ESC-P, ESC-P2, or BJ to select the page
description language or the printer type.
To Next Page
