12-10 IM 701450-01E
12.6 Formatting the Storage Medium
CAUTION
• Do not remove the storage medium (disk) or turn OFF the power when the
access indicator or icon of the storage medium is blinking. Doing so can
damage the storage medium or destroy the data on the medium.
• If the DL7400 cannot recognize a formatted medium, format the disk again on
the DL7400. Note that all the data on the storage medium are cleared when the
storage medium is formatted. Be sure to back up important data beforehand.
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• In the procedural explanation below, the term
jog shuttle & SELECT refers to the operation of
selecting/setting items and entering values using the
jog shuttle and SELECT and RESET keys. For details
on this operation, see sections 4.1 or 4.2.
• For a description of the operation using a USB keyboard
or a USB mouse, see section 4.3.
1. Press FILE. The FILE menu appears.
2. Press the Utility soft key to display the Utility menu and the File List window.
To Next Page
