YOKOGAWA DL7440 User Manual

10-10 IM 701450-01E
10.3 Searching History Waveforms Using Waveform
Parameters (History Search)
<For a description of this function, refer to page 2-25.>
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE MISC RESET SELECT
MATH
SHIFT
GO/NOGO CURSOR MEASURE
HISTORY
PRINT
ACQ START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
1. Press HISTORY. The HISTORY menu appears.
2. Press the Search Mode soft key. The Search Mode menu appears.
3. Press the Parameter soft key.
Setting the Search Parameter and Search Conditions
4. Press the Search Setup soft key. The Search Setup menu appears.
