4.4 Initializing Settings
Procedure
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
Executing Initialization
1. Press SETUP. The SETUP menu appears.
2. Press the Initialize soft key. Initialization is executed.
Execute initialization
Cancel initialization
Canceling Initialization
3. Press the Undo Initialize soft key. The settings return to the conditions that
existed immediately before initialization.
Note
When you turn OFF the power switch, the settings that existed immediately before
initialization are cleared. Therefore, the “Undo” operation is not possible in this case.
