13-44 IM 701450-01E
13.10 Setting the FTP Passive Mode and LPR/SMTP
Timeout
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• In the procedural explanation below, the term
jog shuttle & SELECT refers to the operation of
selecting/setting items and entering values using the
jog shuttle and SELECT and RESET keys. For details
on this operation, see sections 4.1 or 4.2.
• For a description of the operation using a USB keyboard
or a USB mouse, see section 4.3.
1. Press MISC. The MISC menu appears.
2. Press the Network soft key. The Network menu appears.
3. Press the Others soft key. The Others dialog box opens.
Turning ON/OFF FTP the Passive Mode
4. Use jog shuttle & SELECT to select ON or OFF.
Setting the LPR Timeout Time
4. Use jog shuttle & SELECT to set LPR Time Out.
Setting the SMPT Timeout Time
4. Use jog shuttle & SELECT to set SMTP Time Out.
FTP passive mode
LPR timeout time
SMTP timeout time
To Next Page
