YOKOGAWA DL7440 User Manual

2-32 IM 701450-01E
2.7 Communication
Communication Using Commands (GP-IB, USB, or Ethernet) <For the setup
procedure, see the Communication Interface User’s Manual CD-ROM>
The DL7400 comes standard with a GP-IB and a USB interface. An Ethernet interface is
available as an option. Using communication commands, you can output waveform data
to a PC for data analysis or control the DL7400 using an external controller to carry out
waveform measurements.
Communication
interface
PC
DL7400
Saving and Loading Data from a Network Drive (FTP Client) <For the setup procedure,
see section 13.3>
As with the built-in storage medium and external SCSI devices, waveform and setup
data can be saved and loaded and screen image data can be saved to an FTP server*
on the network.
* PC or workstation on which the FTP server function is running.
Ethernet
FTP server
DL7400
Printing on a Network Printer (LPR Client) <For the setup procedure, see section 13.4>
The screen image can be printed on a network printer in the same way as the built-in
printer (optional) or USB printer.
Printer
Ethernet
DL7400
