YOKOGAWA DL7440 User Manual

6-46 IM 701450-01E
6.17 Setting the Trigger Gate
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE MISC RESET SELECT
MATH
SHIFT
GO/NOGO CURSOR MEASURE
HISTORY
PRINT
ACQ START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
1. Press MISC. The MISC menu appears.
2. Press the System Config soft key. The System Config menu appears.
3. Press the Trigger Gate soft key to select OFF, Active High, or Active Low.
