YOKOGAWA DL7440 User Manual

6-45
IM 701450-01E
6
Triggers
Explanation
This setting is for performing a specified action each time the trigger is activated.
Action to Be Performed When the Trigger Condition Is Met
The specified action is performed whenever a trigger is activated.
Buzzer
Sounds a buzzer.
Save to File
Saves the data to the storage medium (floppy disk or Zip disk, PC card, Net Drive
1
, SCSI
device
2
, or USB storage) specified in the FILE menu.
Hard Copy
Outputs the screen image data to the destination (built-in printer, USB, or Net Print
1
) specified
under “Print to” in the PRINT menu.
Image Save
Saves the screen image data to the storage medium (floppy disk, Zip disk, PC card, Net
Drive
1
, SCSI device
2
, or USB storage) specified in the IMAGE menu.
Send Mail
Sends a mail message
1
. Set the number of mail transmission in the range of 1 to 1000. For
details, see section 13.5.
1 When the Ethernet interface option is installed
2 When the SCSI interface option is installed
Note
When the action-on-trigger is started, the specified action is performed when the trigger is
activated in the normal mode regardless of the trigger mode setting.
Action Count
You can set the action count of the action-on-trigger.
1 to 65536 Repeats the action the specified number of counts.
Infinite Repeats the action until waveform acquisition is stopped.
File Name When Save to File or Image Save Is Selected
The file name is automatically assigned by the auto naming function. For details, see
section 12.8 or 12.12.
Trigger Mode
The trigger mode is set to Single.
Note
• Action-on-trigger cannot be used if the acquisition mode is Average.
• Settings cannot be changed while action-on-trigger is in progress.
6.16 Setting the Action-on-Trigger
