YOKOGAWA DL7440 User Manual

4-19
IM 701450-01E
4
Common Operations
4.6 Performing Calibration
Procedure
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
X-Y
PHASE
MENU MENU
SETUP FILE MISC RESET SELECT
MATH
SHIFT
GO/NOGO CURSOR MEASURE
HISTORY
PRINT
ACQ START/STOP
IMAGE SAVE
DISPLAY
1. Press MISC. The MISC menu appears.
2. Press the Calibration soft key. The Calibration menu appears.
3. Press the Auto Cal soft key to select ON or OFF.
4. Press the Cal Exec soft key. Calibration is executed.
