12-1
IM 701450-01E
12
Saving and Loading Data
Chapter 12 Saving and Loading Data
12.1 Storing and Recalling Setup Data
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE
MISC
RESET
SELECT
MATH
SHIFT
GO/NOGO
CURSOR
MEASURE
HISTORY
PRINT
ACQ
START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
1. Press SETUP. The SETUP menu appears.
2. Press the Store/Recall soft key. The Story/Recall menu appears.
Storing Setup Data
3. Press any soft key from Store #1 to Store #3 to store the setup data. When the
setup data is stored, the date of storage is displayed in the soft key menu.
4. Press the Store Detail soft key to display the details of the store operation. To
enter a comment, follow the procedure described in section 4.2. There is a lock
switch that you can use to protect (lock) overwriting the stored data. Turn the
jog shuttle to move the cursor to the lock button corresponding to the store
number that you wish to lock. Press SELECT to lock the data. Press SELECT
again to release the lock.
To Next Page
