17-10 IM 701450-01E
17.12 General Specifications
Item Specifications
Standard operating conditions Ambient temperature: 23±2°C
Ambient humidity: 55±10% RH
Error in supply voltage and frequency: Within 1% of rating
Warm-up time At least 30 minutes
Storage conditions Temperature: –20 to 60°C, –20 to 50°C (for the -J2: built-in Zip drive model)
Humidity: 20 to 80% RH (no condensation)
Operating Conditions Temperature: 5 to 40°C
Humidity: 20 to 80% RH (when the printer is not used) (no condensation)
35 to 80% RH (when the printer is used) (no condensation)
Storage altitude 3000 m or less
Operating altitude 2000 m or less
Rated supply voltage 100 to 120 VAC/220 to 240 VAC
Permitted supply voltage range 90 to 132 VAC/198 to 264 VAC
Rated supply voltage frequency 50/60 Hz
Permitted supply voltage 48 to 63 Hz
frequency range
Power fuse 250 V/6.3 A time lag, VDE/SEMKO/UL/CSA certified.
Inside the case. Cannot be replaced by the user.
Maximum power consumption 320 VA
Withstanding voltage 1.5 kVAC for one minute.
(between power supply and case)
Insulation resistance 10 MΩ or more at 500 VDC.
(between power supply and case)
External dimensions 373 mm (W) × 210.5 mm (H) × 355.3 mm (D)
(details on the next page) (When the printer cover is closed. Excludes the handle and other projections.)
Weight Approx. 10 kg
(only the main unit without the printer)
Instrument’s cooling method Forced air cooling, exhaust from rear.
Installation position Horizontal (the stand can be used to tilt the DL7400), stacking prohibited.
Recommended calibration period 1 year
Battery backup Setup data and clock are backed up with the internal lithium battery
Battery life: Approx. 5 years (at ambient temperature of 23°C)
Standard accessories • Power Cord: 1 piece
• 400 MHz passive probe: 4 pieces
• Soft case: B9969ET, 1 piece
• Front panel protection cover: B8051DP, 1 piece
• Printer roll paper: 1 roll (for /B5 suffix code)
• Rubber feet: 4 pieces (2 A9088ZM)
• User’s manual: 1 piece
• Operation guide: 1 piece
• Communication Interface User’s Manual: 1 piece (CD-ROM)
• Power Supply Analysis Function User’s Manual: 1 piece (for /G4 suffix code)
To Next Page
