YOKOGAWA DL7440 User Manual

17-11
IM 701450-01E
17
Specifications
Item Specifications
Safety Standards Complying standards EN61010-1
• Overvoltage category II
1
• Pollution degree 2
2
Emission Complying standards • EN61326-1 Class A, EN61326-2-1, EN55011 Class A, Group 1,
C-Tick EN55011 Class A, Group 1
(applies to 701450, 701460, 701470, 701480, 700988, 700939, 701941,
701980, and 701981)
• EN61000-3-2
• EN61000-3-3
• This product is a Class A (for industrial environment) product. Operation
of this product in a residential area may cause radio interference in
which case the user is required to correct the interference.
Cable condition • External trigger input/external clock input/trigger gate input terminal
Use a BNC cable
3
and attach a ferrite core (TDK: ZCAT2035-0930A,
YOKOGAWA: A1190MN) on one end (DL7400 end).
• Trigger output terminal
Same as the external trigger input terminal above.
• RGB video signal output (VIDEO OUT) terminal
Use a 15-pin D-Sub VGA shielded cable
3
.
• SCSI connector
Use a SCSI shielded cable
3
and attach a ferrite core (TDK: ZCAT2035-
0930A, YOKOGAWA: A1190MN) on one end (DL7400 end).
• USB PERIPHERAL connector
Attach a ferrite core (TDK: ZCAT1325-0530A, YOKOGAWA: A1181MN)
on one end (DL7400 end) of the USB cable
3
.
• USB interface connector
Attach a ferrite core (TDK: ZCAT1325-0530A, YOKOGAWA: A1181MN)
on one end (DL7400 end) of the USB cable
3
.
• Ethernet interface connector
Use a Ethernet interface cable
4
and attach a ferrite core (TDK:
ZCAT2035-0930A, YOKOGAWA: A1190MN) on one end (DL7400 end).
• Probe power terminal
Attach a ferrite core (TDK: ZCAT1325-0530A, YOKOGAWA: A1181MN)
on one end (DL7400 end) of the cable.
• Logic probe input connector
Attach a ferrite core (TDK: ZCAT2035-0930A, YOKOGAWA: A1190MN)
on one end (DL7400 end) of the cable.
Immunity Complying standards • EN61326-1 Table2 (for use in industrial locations)
EN61326-2-1
(applies to 701450, 701460, 701470, 701480, 700988, 700939, and
701981)
Influence in the immunity environment
• Noise increase: ≤ ±200 mV (when using 700988)
≤ ±400 mV (when using 700939)
No influence (when using 701981)
• Test conditions
When using the 700988: 1 GS/s, envelope mode, 20 MHz BWL, 1 MΩ
input coupling, 50 mV/div (10:1 probe
attenuation setting), and 50-Ω termination at
the probe tip.
When using the 700939: 1 GS/s, envelope mode, 20 MHz BWL, 50 Ω
input coupling, 100 mV/div (10:1 probe
attenuation setting), 50-Ω termination at the
probe tip.
When using the 701981: 1 GS/s, envelope mode, and 50-Ω termination
at the probe tip.
• Cable condition
Same as the cable condition for emission above.
1 The Overvoltage Category (Installation Category) is a value used to define the transient overvoltage condition and includes
the impulse withstand voltage regulation. II applies to electrical equipment that is powered by a fixed installation such as a
distribution board.
2 Pollution Degree applies to the degree of adhesion of a solid, liquid, or gas which deteriorates withstand voltage or surface
resistivity. Pollution Degree 2 applies to normal indoor atmospheres (with only non-conductive pollution).
3 Use cables of length 3 m or less.
4 Use cables of length 30 m or less.
17.12 General Specifications
