YOKOGAWA DL7440 User Manual

8-4 IM 701450-01E
8.2 Performing Display Interpolation
<For a description of this function, refer to page 2-18.>
Procedure
X-Y
PHASE
MENU MENU
SETUP FILE MISC RESET SELECT
MATH
SHIFT
GO/NOGO CURSOR MEASURE
HISTORY
PRINT
ACQ START/STOP
IMAGE SAVE
DISPLAY
• To exit the menu during operation, press ESC located
above the soft keys.
• For a description of the operation using a USB keyboard or
a USB mouse, see section 4.3.
Setting the Interpolation Method
1. Press DISPLAY. The DISPLAY menu appears.
2. Press the Interpolation soft key. The Interpolation menu appears.
3. Press the OFF, Sine, Line, or Pulse soft key to select the interpolation method.
