13-17
IM 701450-01E
13
Ethernet Communications (Optional)
Displaying the Log List
8. Press the Connect Log List soft key. The data and time, user name, and IP
address of the 24 recent accesses are displayed.
Note
• The DL7400 supports two clients, but file operations cannot be performed simultaneously.
• When the DL7400 is accessed from the PC or workstation (login), is displayed at the
upper right corner of the screen.
• This function cannot be used when using the FTP client function, LPR client function, or Web
server function or when performing file operations.
• The log list is cleared when the power is turned OFF.
• To use this function, you must configure TCP/IP in advance according to the procedure given
in section 13.2.
• To activate the settings, you must power cycle the DL7400.
Explanation
The floppy disk drive, Zip disk drive, PC card drive, External SCSI device, or USB
storage on the DL7400 can be accessed from a PC or workstation on the network via the
Ethernet network. To access these drives, FTP client software is needed on the PC or
workstation.
User Account
User Name
You can enter the user name using up to 15 characters. The default setting is
“anonymous.” The characters that can be used are all the ASCII characters on the
keyboard.
Password
You can enter the password using up to 15 characters. The characters that can be used
are all the ASCII characters on the keyboard.
Time Out
The connection to the network is automatically closed if there is no access to the DL7400
for the specified time. The default setting is 5 s. Set the timeout to a long value when
using dedicated FTP client software.
13.6 Accessing the DL7400 from a PC or Workstation (FTP Server Function)
