YOKOGAWA DL7440 User Manual

xi
IM 701450-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
App
Index
Chapter 4 Common Operations
4.1 Operations and Functions of Keys and the Jog Shuttle ................................................... 4-1
4.2 Entering Values and Strings ............................................................................................. 4-3
4.3 Operating the DL7400 Using a USB Keyboard or a USB Mouse .................................... 4-6
4.4 Initializing Settings ......................................................................................................... 4-14
4.5 Performing Auto Setup ................................................................................................... 4-16
4.6 Performing Calibration ................................................................................................... 4-19
4.7 Correcting the Delay Time of the Input Signals .............................................................. 4-21
4.8 Using the Help Function................................................................................................. 4-23
Chapter 5 Vertical and Horizontal Axes
5.1 Turning Channels ON/OFF .............................................................................................. 5-1
5.2 Setting V/div ..................................................................................................................... 5-2
5.3 Setting the Vertical Position of the Waveform .................................................................. 5-4
5.4 Setting the Input Coupling................................................................................................ 5-6
5.5 Selecting the Probe Attenuation/Current-to-Voltage Conversion Ratio ............................ 5-8
5.6 Setting the Offset Voltage ................................................................................................ 5-9
5.7 Using the Preset Function .............................................................................................. 5-11
5.8 Setting Bandwidth Limits ................................................................................................ 5-14
5.9 Using the Linear Scaling Function ................................................................................. 5-15
5.10 Turning ON/OFF the Logic Input and Setting the Threshold Level ................................ 5-17
5.11 Selecting the Time Base ................................................................................................ 5-20
5.12 Setting T/div ................................................................................................................... 5-22
Chapter 6 Triggers
6.1 Selecting the Trigger Mode .............................................................................................. 6-1
6.2 Setting the Trigger Position .............................................................................................. 6-3
6.3 Setting the Trigger Delay ................................................................................................. 6-5
6.4 Setting the Hold Off Time ................................................................................................. 6-6
6.5 Setting the Edge Trigger (SIMPLE) .................................................................................. 6-9
6.6 Setting the External Trigger (SIMPLE) ........................................................................... 6-12
6.7 Activating Triggers on the Commercial Power Supply (SIMPLE) .................................. 6-14
6.8 Setting the A->B(N) Trigger (ENHANCED) .................................................................... 6-15
6.9 Setting the A Delay B Trigger (ENHANCED) ................................................................. 6-18
6.10 Setting the Pattern Trigger (ENHANCED) ..................................................................... 6-21
6.11 Setting the Width (Pulse<Time, Pulse>Time, T1<Pulse<T2, and Time Out) Trigger
(ENHANCED) ................................................................................................................ 6-25
6.12 Setting the OR Trigger (ENHANCED) ............................................................................ 6-30
6.13 Setting the Window Trigger (ENHANCED) .................................................................... 6-33
6.14 Setting the TV Trigger (ENHANCED) ............................................................................ 6-36
6.15 Setting the Logic Trigger (ENHANCED, Optional) ......................................................... 6-41
6.16 Setting the Action-on-Trigger ......................................................................................... 6-44
6.17 Setting the Trigger Gate ................................................................................................. 6-46
Chapter 7 Waveform Acquisition
7.1 Starting/Stopping Waveform Acquisition .......................................................................... 7-1
7.2 Setting the Record Length ............................................................................................... 7-2
7.3 Using Interleave Mode ..................................................................................................... 7-3
7.4 Turning ON/OFF Repetitive Sampling Mode ................................................................... 7-4
7.5 Setting the Acquisition Mode ............................................................................................ 7-6
7.6 Performing Sequential Store (SINGLE(N) Mode) .......................................................... 7-10
Contents
