7-11
IM 701450-01E
7
Waveform Acquisition
Acquisition Count
You can set the acquisition count. The acquisition count that can be specified varies
depending on the specified record length as follows.
Count When in Normal Mode Count When in Box Average Mode
Specified Record 16 MW memory 4 MW memory 16 MW memory 4 MW memory
Length model model model model
1 kW 1 to 2048 (4096) 1 to 1024 (2048) 1 to 2048 (4096) 1 to 512 (1024)
10 kW 1 to 256 (512) 1 to 128 (256) 1 to 256 (512) 1 to 64 (128)
50 kW 1 to 64 (128) 1 to 32 (64) 1 to 64 (128) 1 to 16 (32)
100 kW 1 to 32 (64) 1 to 16 (32) 1 to 32 (64) 1 to 8 (16)
250 kW 1 to 16 (32) 1 to 8 (16) 1 to 16 (32) 1 to 4 (8)
500 kW 1 to 8 (16) 1 to 4 (8) 1 to 8 (16) 1 to 2 (4)
1 MW 1 to 4 (8) 1 to 2 (4) 1 to 4 (8) 1 (2)
2 MW 1 to 2 (4) 1 (2) 1 to 2 (4) –(1)
4 MW 1 (2) –(1) 1 (2) –
8 MW 1 (1) – –(1) –
16 MW –(1) – – –
* The value inside the parentheses is selectable only when interleave mode is ON.
Displaying Waveforms
You can recall waveforms from memory in the same fashion as with the history memory
function. For details, see section 10.1.
Note
• Sequential store is not possible when in repetitive sampling mode or roll mode.
• If you stop waveform acquisition by pressing the START/STOP key, the sequential store
operation also stops. If restarted, the acquisition count is reset, and waveform is acquired
from the first waveform.
7.6 Performing Sequential Store (SINGLE(N) Mode)
To Next Page
