12-5
IM 701450-01E
12
Saving and Loading Data
Procedure When the Zip Disk Cannot Be Ejected
If the Zip disk cannot be removed by performing the steps above, carry out the following
steps to remove it.
Insert a pin of approximately 1 mm in diameter into the eject button hole and press
slowly. This will cause the Zip disk to be ejected.
Eject button of the Zip dis
Insert a pin
Zip disk eject hole
CAUTION
• Removing the Zip disk while the access indicator is ON may destroy the data on
the Zip disk.
• Do not use the Zip drive if the DL7400 is installed in a tilted position using the
stand. (For the installation position, see section 3.2.)
• When turning ON/OFF the DL7400, have the Zip disk removed from the drive.
• Do not insert the Zip disk into the drive, or remove the Zip disk from the drive
while the DL7400 is starting up after turning ON the power (see section 3.3,
"Power Up Operation"). Doing so can damage the disk.
• The access indicator illuminates immediately after the Zip disk is inserted. Do
not operate the DL7400 while the access indicator is illuminated. Doing so can
lead malfunction.
General Handling Precautions of Zip Disks
For the general handling precautions of the Zip disk, read the instruction manual that
came with the Zip disk.
PC Cards
PC Cards That Can Be Used
The DL7400 supports flash ATA cards (PC card TYPE II) and compact flash (using the
PC card TYPE II adapter). In addition, some of the Flash ATA HDD cards can be used.
For details, contact your nearest YOKOGAWA dealer.
Note
To use the PC card on the PC, use a PC that supports the PC card. Depending on the PC
that you are using, the PC cards indicated above may not operate properly. Check it
beforehand.
12.2 Floppy Disk, Zip Disk, and PC Cards
