3-4 IM 701450-01E
Ambient Temperature and Humidity
Ambient temperature 5 to 40°C
Ambient humidity 20 to 80% RH (when the printer is not used)
35 to 80% RH (when using the printer)
In either case, no condensation should be present.
Note
• To ensure high measurement accuracy, operate the instrument in the 23 ± 5°C temperature
range and 55 ± 10% RH.
• Condensation may occur if the instrument is moved to another place where the ambient
temperature is higher, or if the temperature changes rapidly. In such cases, allow the
instrument adjust to the new environment for at least an hour before using the instrument.
Do not install the instrument in the following places.
• In direct sunlight or near heat sources.
• Where an excessive amount of soot, steam, dust, or corrosive gas is present.
• Near strong magnetic field sources.
• Near high voltage equipment or power lines.
• Where the level of mechanical vibration is high.
• On an unstable surface.
Installation Position
Place the instrument in a horizontal position or inclined position using the stand (see the
figure below). When using the stand, pull it forward until it locks. To retract it, set the
stand back to its original position.
Rubber Feet
If the instrument is installed in a tilted position as shown in the figure above, rubber
stoppers can be attached to the feet to prevent the instrument from sliding. Four rubber
feet are included in the package.
3.2 Installing the Instrument
To Next Page
