4-4 IM 701450-01E
Entering Strings
The keyboard displayed on the screen is used to enter character strings such as file
names and comments. The jog shuttle, SELECT, and arrow keys are used to operate
the keyboard to enter the character strings.
Operating the Keyboard
1. Turn the jog shuttle to move the cursor to the character to be entered. You can
also press the soft keys corresponding to and to move the cursor
vertically.
2. Press SELECT key to enter the character. If a character string has already
been entered, move the cursor to the position in the string at which you want to
enter a character.
3. Repeat steps 1 and 2 to enter all the characters in the string.
4. Selecting ENT on the keyboard and pressing SELECT confirms the string and
the keyboard disappears. You can also press the ENT soft key to confirm the
string and clear the keyboard. At the same time, the confirmed string is
temporarily stored. If you wish to clear the entire string that you have entered,
press RESET before confirming the string.
Recalls the temporary stored string.
See "Recall" described later.
CAPS: Uppercase characters
Confirms the displayed characters.
Switches the insert/overwrite mode.
Deletes the character before the entry position.
Switches between uppercase and lowercase
and a portion of the symbols.
Moves the cursor downward.
Moves the cursor upward.
CAPS: Lowercase characters
Note
When using the user-defined computation (option, see section 9.9), a keyboard for setting the
computation appears. The basic setup procedure is the same as the procedure explained
here.
4.2 Entering Values and Strings
To Next Page
