CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 3.3 Platen Wall Adjustment
3 - 25
3
Search
Book TOC
Go Back
Figure 3-8 Rack Guide Alignment
--- END ---
Left Rack
Guide
Rack Flanges
Right Rack
Guide
Tight Fit
Tool Seats Fully
Tight Fit
Tool Seats Fully
SL-272
4
3
2
1
Beam
Block
Tool Will Not Lie Flat In
Areas 2, 3. Stand Tool On
End With Cut Out Facing Up.
