28 Oct
1997 21:57
CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 4.1 Rack Sensor Check
3 - 61
3
Search
Book TOC
Go Back
When E Sensor is blocked, any other sensors blocked will cause a Flashin
g
LED for that
sensor.
Example:
B blocked and E blocked = LED II Flashin
g
B blocked, E NOT blocked, = LED II
ON.
7. Verify E Sensor is
ON
just before B Sensor.
a. Place normal rack at D Sensor (Fi
g
ure 3-28).
b. Ensure LED IV is
ON
.
c. Slowly move another normal rack into position at B Sensor (Fi
g
ure 3-28) while observin
g
LEDs II and IV.
d. Verify LED IV flashes just before LED II.
e. If check fails,
g
o to “VP - 4.2 Rack Sensor Adjustment” (Pa
g
e 3-63).
