VERIFICATION PROCEDURES
VP - 6.4 Mixing Contact Sensor Check/Adjustment
3 - 95
3
Search
Book TOC
Go Back
Figure 3-48 [NON-CE MARK] E Loader Contact Sensor
G Loader [CE MARK and NON-CE MARK]
Top of Mixin
g
Paddle must be flush with bottom of Sensor (Fi
g
ure 3-49) when Mixin
g
Head is
in Home Position (Z
↑
).
[NON- CE MARK]
SL-277
Top of Paddle
Flush with Bottom
of Sensor
Contact
Sensor
