CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 6.4 Mixing Contact Sensor Check/Adjustment
3 - 96
3
Search
Book TOC
Go Back
Figure 3-49
6. Verify Contact Sensor clearance.
[
CE MARK ]
Clearance Check is
NOT
required.
[NON- CE MARK ]
Mixin
g
Paddle must clear Sensor by .010-015in. (0.25-0.38mm.); .015in.
(0.38mm) preferred (Fi
g
ure 3-50, Pa
g
e-3-97).
SL-271
Flush With
Bottom of Sensor
All G Loaders
G Loader
