CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 6.4 Mixing Contact Sensor Check/Adjustment
3 - 98
3
Search
Book TOC
Go Back
8. Verify Contact Sensor switchin
point.
All Loaders
a. Ensure Loader is in Manual Mode.
b. Press (
←
X) to move X-Axis Solenoids to left stop.
c. Insert Rack Guide Ali
nment Tool in ri
ht end of Platen with cutout facin
up and to the left
(Fi
ure 3-51, Pa
e-3-99).
d. Load Mixin
Head Ali
nment in Position #4 of Rack and place Rack on left end of Platen
under the Tower.
e. Press (
→
X) to move Rack into cutout. Mixin
Head Tool should be under Mixin
Paddle (Fi
-
ure 3-51).
f. Press (Z
↓
) to drive Mix Paddle into Ali
nment Tool until Contact Sensor is blocked accordin
to Table 3-6, Fi
ure 3-52, Pa
e-3-100.
NOTE:Turn Z2 Motor Lead Screw with fingers to block Sensor accurately
