CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 9.1 Sample Wash Block Check/Adjustment
3 - 126
3
Search
Book TOC
Go Back
Figure 3-67 Sample Needle Alignment Setup
6. If check fails:
a. Perform “VP - 3.8 Rack to Laser Shield Check” (Pa
g
e 3-39) and “VP - 3.16 X-Axis Solenoid to
Rack Guide Check” (Pa
g
e 3-55).
Needle Ali
g
nment Tool
in Tube Position # 3
Drive
Needle
into Hole
in Tool
( ↑ N ↓ )
Place Rack Guide
Ali
g
nment Tool
with Cutout Up
and Facin
g
Left
SL-179A
# 3
