CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 9.1 Sample Wash Block Check/Adjustment
3 - 127
3
Search
Book TOC
Go Back
b. Loosen Wash Block Mountin
Screws (Fi
ure 3-68).
NOTE:E Loader - If a spacer has been added under the left side of the mounting block, DO NOT
REMOVE.
c. Move Wash Block to ali
n needle in Tool.
NOTE:New style and old style Wash Blocks are adjusted the same way.
d. If a spacer is under the Wash Block, perform “VP - 13.1 Lead Bubble Check/Adjustment”
(Pa
e 3-154).
