CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 11.2 Barcode Adjustment
3 - 147
3
Search
Book TOC
Go Back
4. Ali
n Barcode Beam Position:
a. Remove covers.
b. Block safety cover sensor (rear of unit, left of tower).
c. Set up Sample Loader accordin
to Steps 1, 2, and 3 of “VP - 11.1 Barcode Check” (Pa
e
3-141).
d. Disconnect tubin
from Analyzer to Sample Loader. DO NOT kink Sample Tubin
.
e. Turn Sample Loader to access rear.
f. Perform Steps 4, 5, and 6 of “VP - 11.1 Barcode Check” (Pa
e 3-141).
. As Barcode Ali
nment Test is runnin
, loosen Barcode Head Bracket (2 screws) and ali
n red
beam on center of barcode (Fi
ure 3-79).
NOTE:Use the same adjustment procedure for both [NEW] and [OLD] Barcode Readers.
CAUTION:[NEW ONLY] The Barcode adjusting Bracket may contact the Tube Pusher Arm on
some Loaders. If gap between bracket and arm is less than .020”(0.5mm), install Bar-
code Bracket (PN 9311273).
h. Li
htly shift rack left and ri
ht.
i. Ensure “
TEST
” displays every time.
