CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 14.1 Y-Axis Operation Check/Adjustment
3 - 160
3
Search
Book TOC
Go Back
b. Press
Y
a
g
ain. Pusher Arm should retract immediately and not extend farther into Platen.
5. If Step 3 check fails, perform the followin
g
steps:
a. Remove Platen.
b. Loosen 2 set screws at left end of shaft (Fi
g
ure 3-86, Pa
g
e-3-162).
c. Adjust Y-Axis Drive Mechanism.
d. Pull both Push Arm slides away from platen.
e. Verify Connectin
g
Bars are Horizontal.
f. Verify position of Sensor Fla
g
s.
- Ensure slot in Home Sensor Fla
g
is positioned properly (see Fi
g
ure 3-86).
g
.Ti
g
hten set screws on left end of shaft.
h. Check Drive Belt tension.
i. Ti
g
hten all Y-Axis hardware.
j. Install Platen and perform all Platen checks (VP-3.1-3.16).
