CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 15.1 Barcode Reader Configuration (Europe Only)
3 - 167
3
Search
Book TOC
Go Back
- Press
[ESC]
key.
- Press
[E]
key.
- Press
[Y]
key.
Loader beeps to confirm new settin
g
s.
14.Press
[F10]
to Exit to the
A:\
prompt.
Figure 3-88 Barcode Programming Link Cable
END
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
BCR
[female]
Computer
[female]
GND
DTR
TxD
RxD
RxD
TxD
DTR
GND
CTS
DSR
9-Pin9-Pin
Cable Should be
≈
2m (6ft) Long
SL-257
Directly to the Barcode
reader cable (unplugged
from CH2)
To Port labeled "External
Computer" of Data Station or
"COM1" of any computer
running vbcdiag.exe.
