CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
Appendix 3 A - Sensors, LEDs and POTs
3 - 169
3
Search
Book TOC
Go Back
E Rack Sensor
(below B
Sensor)
Other Active
Sensors Flash
with Normal
Rack
CE MARK: TP 1
NON-CE MARK: TP
Header, Pin 8
CE MARK Blocked: 0.5 -
1.0V
NON-CE MARK
Blocked: 5V
UnBlocked: 0V
R1
VR5
4.1
4.2
Blood In-Line
Sensor
On Sensor BD
in Tower
LED On = Clear
LED Off =
Blood In-Line
CN 5, PIN 23
TP Header, Pin 17
Blood In-Line: 5V
Clear: 0V
See
VP
12.1
Interlock Sensor N/A CE MARK: CN 5, PIN
24
NON-CE MARK: TP
Header, Pin 18
Blocked: 5V
UnBlocked: 0V
N/A N/A
Mixer, Contact
(Tube Position)
Repeat CE MARK: TP 11
NON-CE MARK: TP
Header, Pin 6
CE MARK Blocked: 3.9V
NON-CE MARK
Blocked: 5V
UnBlocked: 0V
R7
VR6
6.4
Mixer, Home N/A CE MARK: CN 5, PIN
4
NON-CE MARK: TP
Header, Pin 2
Blocked: 5V
UnBlocked: 0V
N/A 6.3
Table 3 - 7
Sensor LED Test Point Normal Voltages POT VP#
