CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
Appendix 3 A - Sensors, LEDs and POTs
3 - 171
3
Search
Book TOC
Go Back
X-Axis, Limit N/A CE MARK: CN 4, PIN
15
NON-CE MARK: TP
Header, Pin 7
Blocked: 5V
UnBlocked: 0V
N/A 3.16
3.17
Y-Axis, Home N/A CE MARK: CN 4, PIN
4
NON-CE MARK: TP
Header, Pin 9
Blocked: 5V
UnBlocked: 0V
N/A 14.1
Y-Axis, Position N/A CE MARK: CN 4, PIN
10
NON-CE MARK: TP
Header, Pin 11
Blocked: 5V
UnBlocked: 0V
N/A 14.1
Table 3 - 7
Sensor LED Test Point Normal Voltages POT VP#
