Page #272 background image
6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.1.1 6241A Source and Measurement
9-6
Settling time:
The time it takes to settle to the final value ±0.1 % when varying from zero to the full scale.
Setting conditions: Source values and limiter values are full-scale settings.
Load conditions: Resistive load and 200 pF max. load capacitance
Overshoot: ±0.1% max. Resistive load, at end of standard cable (excluding
30 μA, 300 μA ranges)
Line regulation: ±0.003 % of range or less
Load regulation: Voltage-source; ±0.003 % of range or less (At 4-wire connection with
maximum load)
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage-source
(Output current: 500 mA)
300 mV
500 mA
200 μs or less 1 ms or less
3 V 70 μs or less 400 μs or less
30 V 300 μs or less 1.5 ms or less
Current-source
(Output voltage: 30 V)
30 μA
30 V
2 ms or less 3.5 ms or less
300 μA
600 μs or less 2.5 ms or less
3 mA
30 mA
300 mA
500 mA 700 μs or less 3 ms or less
Typical value
Source
range
Limiter
range
Settling time
Output response
FAST SLOW
Voltage-source
(Output current: 20% max. full-scale)
300 mV
3 mA to
300 mA
35 μs or less 300 μs or less
3 V 30 μs or less 200 μs or less
30 V 100 μs or less 500 μs or less
Current-source
(Output voltage: 1 V)
30 μA
3 V
800 μs or less 1 ms or less
300 μA
30 μs or less 200 μs or less
3 mA
30 mA
300 mA
500 mA 50 μs or less 250 μs or less
