6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.1.2 6242 Source and Measurement
9-12
The full-scale item tolerance listed below, is added to the integration time 10 ms to 100 μs measurement
accuracy and 1-day stability.
S/H: Measurement in sample hold mode (Integration time: 100 μs)
When LO OUTPUT is grounded to the chassis, the additional error of integration time in the 30 μA range
is the same as that in 300 μA range.
Source linearity: ±3 digits or less (5 A range is ±5 digits or less)
Maximum output current: 0 to ±6 V; ±5 A
Maximum Compliance-voltage: 5 A up to; 0 to ±6 V
Measurement
range
Integration time
unit: digits (at 5
1
/
2
digit display)
10 ms 5 ms 1 ms 500 μs 100 μsS/H
Voltage-mea-
surement
300 mV 10 15 20 30 60 200
3 V 5 8 10153050
6 V 5 8 10153050
Current mea-
surement
30 μA 200 300 300 300 300 300
300 μA 2030303070100
3 mA 10 30 30 30 50 80
30 mA 10 30 30 30 50 100
300 mA 10 15 15 15 50 100
3 A 20 30 75 75 250 500
5 A 20 30 75 75 250 500
To Next Page
