Agilent Technologies 8960 Series Reference Guide

258
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_afgenerator.fm
AFGenerator
AFGenerator:VOLTage:AMPlitude
AFGenerator:VOLTage:STATe
Function Sets/queries the amplitude for the audio generator when the audio generator state is on. The
units (V|mV) are optional. If no units are specified, then units default to V.
Setting Range: 0 to 9 V pk.
Resolution:
• 0.5 mV pk. <= 1 V pk. output
• 5 mV pk. > 1 V pk. output
Query Range: 0 to 9 V pk.
Resolution:
• 0.5 mV pk. <= 1 V pk. output
• 5 mV pk. > 1 V pk. output
*RST setting 0 V
Programming Example
OUTPUT 714;"AFGENERATOR:VOLTAGE:AMPLITUDE 1.414" !Sets the audio generator output
!voltage to 1.414 volts peak.
Function Sets/queries the audio generator state
Setting 0 | OFF | 1 |ON
Query 0|1
*RST setting 0 (off)
Programming Example
OUTPUT 714;"AFGENERATOR:VOLTAGE:STATE ON" !Set the audio generator state to ON.
