Agilent Technologies 8960 Series Reference Guide

257
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_afgenerator.fm
AFGenerator
AFGenerator:VOLTage[:SAMPlitude]
Function Sets /queries the amplitude of the audio generator in volts and turns the state to on. The units
(V|mV) are optional. If no units are specified, then units default to V.
Setting Range: 0 to 9 V pk.
Resolution:
• 0.5 mV pk. <= 1 V pk. output
• 5 mV pk. > 1 V pk. output
Query Range: 0 to 9 V pk.
Resolution:
• 0.5 mV pk. <= 1 V pk. output
• 5 mV pk. > 1 V pk. output
*RST setting 0 V
Programming Example
OUTPUT 714;"AFGENERATOR:VOLTAGE 2.1" !Sets the state to on and the output
!voltage to 2.1 volts.
