CALibration
CALibration:CPOWer?
CALibration:DAPower?
Function Initiates IF level calibration used by access probe power and channel power measurements.
No other GP-IB commands are processed until this calibration has completed.
Query Range
• 0 = Calibration passed
• 1 = Channel power calibration failed due to temperature drift. Wait for temperature to
stabilize.
• 2 = Channel power calibration failed due to oven temperature out of range.
• 3 = Channel power calibration failed due to loopback switch problem.
•
−340 = Calibration failed
Programming Example
OUTPUT 714;"CALIBRATION:CPOWer?"
!Initiates the IF level calibration process and queries the pass/fail result.
Function Initiates digital average power measurement calibration.
RF power must not be applied to the test set’s front panel RF IN/OUT connector during
calibration.
Digital average power measurement calibration will take about 10 minutes.
Power must be cycled when digital average power measurement calibration has completed.
No other GP-IB commands are processed until this calibration has completed.
Query Range
• 0 = Calibration passed
• 1 = Digital average power calibration failed due to temperature drift. Wait for temperature to
stabilize.
• 2 = Digital average power calibration failed due to oven temperature out of range.
• 3 = Digital average power calibration failed due to loopback switch problem.
•
−340 = Calibration failed
Programming Example
OUTPUT 714;"CALIBRATION:DAPower?"
!Initiates the digital average power measurement calibration process and queries the pass/fail
result.
