CALibration
CALibration:IQ[:1]?
NOTE When the the calibration is done the test set display will display:
IQ Calibration completed successfully for modulator 1.
CALibration:IQ2?
NOTE When the the calibration is done the test set display will display:
IQ Calibration completed successfully for modulator 2.
Function Sets/queries the calibration of the IQ modulator for RF generator 1. It takes some time to
complete calibration and can’t be aborted except by cycling the power switch.
• Calibrates the IQ modulator for RF generator 1.
• Returns a value indicating success or failure of calibration.
Query Range
• 0 = Pass
•
−340 = Fail
Programming Example
OUTPUT 714;”CALIBRATION:IQ1?”
!Performs a calibration of the IQ modulator for RF generator 1 and returns 0 or -340
Function Sets/queries the calibration of the IQ modulator for RF generator 2. It takes some time to
complete calibration and can’t be aborted except by cycling the power switch.
• Calibrates the IQ modulator for RF generator 2.
• Returns a value indicating success or failure of calibration.
Query Range
• 0 = Pass
•
−340 = Fail
Programming Example
OUTPUT 714;”CALIBRATION:IQ2?”
!Performs a calibration of the IQ modulator for RF generator 2 and returns 0 or -340
