CALL:SCHannel
CALL:SCHannel:DRATe:RCONfig1
CALL:SCHannel:DRATe:RCONfig2
CALL:SCHannel:DRATe:RCONfig3
CALL:SCHannel:DRATe:RCONfig4
Function Sets/queries the data rate of the radio configuration 1 (RC1) forward supplemental channel
(SCH) in bits per second.
Setting Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600
Query Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600
*RST Setting BPS9600
Programming Example
OUTPUT 714;"CALL:SCHANNEL:DRATE:RCONFIG1 BPS38400"
Function Sets/queries the data rate of the radio configuration 2 (RC2) forward supplemental channel
(SCH) in bits per second.
Setting Range: BPS14400|BPS28800|BPS57600|BPS115200|BPS230400
Query Range: BPS14400|BPS28800|BPS57600|BPS115200|BPS230400
*RST Setting BPS14400
Programming Example
OUTPUT 714;"CALL:SCHANNEL:DRATE:RCONFIG2 BPS28800"
Function Sets/queries the data rate of the radio configuration 3 (RC3) forward supplemental channel
(SCH) in bits per second.
Setting Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600
Query Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600
*RST Setting BPS9600
Programming Example
OUTPUT 714;"CALL:SCHANNEL:DRATE:RCONFIG3 BPS38400"
Function Sets/queries the data rate of the radio configuration 4 (RC4) forward supplemental channel
(SCH) in bits per second.
Setting Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600|BPS307200
Query Range: BPS9600|BPS19200|BPS38400|BPS76800|BPS153600|BPS307200
*RST Setting BPS9600
Programming Example
OUTPUT 714;"CALL:SCHANNEL:DRATE:RCONFIG4 BPS76800"
