CALL:SETup:MS:ANALog
CALL:SETup:MS:ANALog:TXLevel:CELLular
Function Sets/queries the mobile power level to be used when originating a call on an AVC, or when
performing a handoff to an AVC in the cellular (800 MHz) band, when in active cell operating
mode.
In AVC Test operating mode, this command immediately changes the expected analog MS TX
level.
Setting Range: 0 to 7
MS TX Level 0: expected power, 36 dBm*
MS TX Level 1: expected power, 32 dBm
MS TX Level 2: expected power, 28 dBm
MS TX Level 3: expected power, 24 dBm
MS TX Level 4:expected power, 20 dBm
MS TX Level 5: expected power, 16 dBm
MS TX Level 6: expected power, 12 dBm
MS TX Level 7: expected power, 8 dBm
*all values for MS TX level assume 0 dB antenna gain
Query Range: 0 to 7
*RST Setting 2
Programming Example
OUTPUT 714;”CALL:SETUP:MS:ANALOG:TXLEVEL:CELLULAR 5”
!Sets the handoff transmit power level to 5 in the cellular band.
