399
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_call_status.fm
CAL L: S TATus
CALL:STATus:TOTal:POWer[:AMPLitude][:SELected]?
CALL:STATus:TOTal:POWer:STATe[:SELected]?
CALL:STATus:TRAFfic:LEVel[:SELected]?
Function Queries the total RF power of the currently selected system type.
The total RF power is equal to the sum of the cell power setting (see “CALL[:CELL]:POWer” ) and
the AWGN setting (see “CALL:AWGNoise:POWer” ).
The optional [:SELected] keyword in this command specifies that the total RF power level being
queried applies to the current system type.
Query Range: -170 dBm/1.23 MHz to 35 dBm/1.23 MHz (including amplitude offset), 9.91 E+37
Resolution: 0.01 dB
*RST Setting 9.91 E+37
Programming Example
OUTPUT 714;"CALL:STATUS:TOTAL:POWER:AMPLITUDE:SELECTED?"
Function Queries the current total RF power measurement’s state for the currently selected system type.
This query will return a 1 (on) if either current cell power (“CALL[:CELL]:POWer” ) or current
AWGN (“CALL:AWGNoise:POWer” ) power states are on.
The optional [:SELected] keyword in this command specifies that the power state being queried
applies to the current system type.
Query Range: 1|0
*RST Setting 0 (off)
Programming Example
OUTPUT 714;"CALL:STATUS:TOTAL:POWER:STATE:SELECTED?"
Function Queries the current forward traffic channel level.
The forward fundamental channel level is set using the “CALL:TRAFfic:LEVel[:SELected]”
commands.
The optional [:SELected] keyword in this command specifies that the traffic channel level being
queried applies to the current system type.
Query Range: 0 to 30 dB, 9.91 E+37
Resolution: 0.01 dB
*RST Setting 9.91 E+37
Programming Example
OUTPUT 714;"CALL:STATUS:FCHANNEL:LEVEL?"
