FETCh:CTXSpurious
FETCh:CTXSpurious[:ALL]?
FETCh:CTXSpurious:ICOunt?
Function Queries the TX spurious emissions measurement results.
This measurement returns results in the following order: integrity, TX spurious emissions
pass/fail result, lower adjacent channel (-0.885 or -1.25 MHz) average TX spurious emissions,
upper adjacent channel (+0.885 or +1.25 MHz) average TX spurious emissions, lower alternate
channel (-1.98 MHz) average TX spurious emissions, upper alternate channel (+1.98 MHz)
average TX spurious emissions.
Query Integrity
• Range: 0 to 23 see “Integrity Indicator”
• Resolution: 1
TX spurious emissions pass/fail result
• Range: 0 to 1 (0 = passed, 1 = failed), 9.91 E+37
Lower adjacent channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Upper adjacent channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Lower alternate channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Upper alternate channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Programming Example
OUTPUT 714;"FETCH:CTXSPURIOUS?"
Function Queries the intermediate count of measurements completed in a multi-measurement.
The multi-measurement state, by default, is off. To set up multi-measurements, see
“SETup:CTXSpurious:COUNt[:SNUMber]” .
Query Range: 0 to 999
Programming Example
OUTPUT 714;"FETCH:CTXSPURIOUS:ICOUNT?"
