READ
READ:HWQuality[:ALL]?
Function Initiates and fetches the handoff waveform quality measurements as a sequential operation.
Measurement results are returned in the following order: integrity, rho, frequency error, time
error, carrier feedthrough, phase error, magnitude error.
Query Integrity
• Range: 0 to 23
• Resolution: 1
Rho
• Range: 0.000 to 1.000, 9.91 E+37
• Resolution: 0.001
Frequency Error
• Range: -9999.0 to 9999.0 Hz, 9.91 E+37
• Resolution: 0.1 Hz
Time Error
• Range-99.99 to 99.99
µs, 9.91 E+37
• Resolution: 0.01
µs
Carrier Feedthrough
• Range: -100 to 0.0 dB, 9.91 E+37
• Resolution: 0.1
Phase Error
• Range: -180.0 to 180.0 degrees
• Resolution: 0.1
Magnitude Error
• Range: 0 to 100%, 9.91 E+37
• Resolution: 0.01
