Agilent Technologies 8960 Series Reference Guide

508
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_setup_afan.fm
SETup:AFANalyzer
SETup:AFANalyzer:COUNt:STATe
SETup:AFANalyzer:DEMPhasis:STATe
SETup:AFANalyzer:DETector[:TYPE]
SETup:AFANalyzer:EXPandor[:SRLevel]
Function Sets/queries the multi-measurement state of the AF analyzer measurement.
Setting Range: 1|ON|0|OFF
Query Range: 1|0
*RST Setting 0 (off)
Programming Example
OUTPUT 714;"SETUP:AFANALYZER:COUNT:STATE ON” !Turns on multi-measurements.
Function Sets/queries whether 750 us de-emphasis is enabled.
Setting Range: 1|ON|0|OFF
Query Range: 1|0
*RST Setting 0 (off)
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:DEMPHASIS:STATE ON”
Function Sets/queries the detector type for audio level measurements.
Setting Range: RMS|PEAK
Query Range: RMS|PEAK
*RST setting RMS
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:DETECTOR:TYPE PEAK”
Function Sets/queries the expandor’s reference level and automatically sets the expandor’s state to ON.
Setting Range: 10 mV to 10 V
Resolution: 1 mV
Query Range: 10 mV to 10 V
*RST setting 1 V
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:EXPANDOR:SRLEVEL 5V”
!Sets expandor state to on and level to 5 V.
